Graphing calculator guide

Find RREF on a TI-84 or TI-83 Plus.

Enter a matrix, return to the home screen, and run the rref( command.

1. Enter your matrix.

Press 2nd, then x⁻¹ to open the MATRIX menu. Press → twice to reach EDIT, then press ENTER to edit matrix [A]. Type the number of rows and press ENTER, type the number of columns and press ENTER, then type each value followed by ENTER.

2. Open the RREF command.

Leave the editor with 2nd, then MODE (QUIT). Press 2nd, then x⁻¹ again and press → once to reach MATH. Press ALPHA, then APPS to paste rref( on the home screen.

3. Choose the stored matrix.

Press 2nd, x⁻¹, then 1 to insert [A] from the NAMES list. Close the parenthesis with ) and press ENTER. The expression is rref([A]), and the reduced matrix appears below it.

Expected result for [[1,2,3],[2,5,8]]
RREF of the 2 by 3 example matrix
10−1
012

These instructions cover the TI-83 Plus and TI-84 Plus families. Check the official guide for your model. This website is independent of Texas Instruments.

Where is rref on a TI-84 calculator?

On TI-83 Plus and TI-84 Plus models, rref( is in the MATH list of the MATRIX menu, which opens with 2nd and x⁻¹. Instead of scrolling down the MATH list, press ALPHA then APPS to paste it directly.

ref( or rref(: which one to use.

The same MATH list holds two commands. ref( (item A, pasted with ALPHA MATH) gives a row echelon form: zeros below each pivot only. rref( (item B, pasted with ALPHA APPS) gives the reduced row echelon form, with zeros above and below every pivot. For solving a system, use rref(: the answer can be read straight from the last column, and it is unique, so it matches your textbook. The calculator's ref( result may look different from a hand-worked REF and still be correct; REF vs. RREF shows why.

Read the solution of a system.

To solve 2x + y − z = 8, −3x − y + 2z = −11 and −2x + y + 2z = −3, store the augmented matrix as [A], with the constants in the last column, and run rref([A]):

Augmented matrix [A]
Augmented matrix of the system
21−18
−3−12−11
−212−3
rref([A])
RREF of the augmented matrix
1002
0103
001−1

The TI-84 does not draw the divider line; the last column is still the constants. There are three possible outcomes:

  • One solution: the left part is the identity matrix, as here. The last column gives x = 2, y = 3, z = −1.
  • No solution: a row is all zeros except its last entry, which reads 0 = 1.
  • Infinitely many solutions: no row reads 0 = 1, but a coefficient column has no leading 1. That variable is free.

The augmented matrix calculator names the outcome and writes the free-variable solution for you.

Show the answer as fractions.

The home screen shows decimals by default, so a result such as 1/3 appears as .3333333333. To display the reduced matrix with fractions, put the cursor after rref([A]), press MATH, choose ▸Frac and press ENTER. The full expression reads rref([A])▸Frac. This conversion step is not part of the Texas Instruments article cited below; if your model's MATH menu differs, check its guidebook.

Fix common problems.

ERR:INVALID DIM

According to the TI-Basic Developer reference, rref( and ref( give ERR:INVALID DIM when the matrix has more rows than columns. A 4×3 matrix, for example, triggers it. Add columns of zeros on the right until there are at least as many columns as rows. Zero columns never gain a pivot and stay zero under every row operation, so the reduced matrix is the true RREF with the zero columns still attached. The online calculator accepts tall matrices directly.

Tiny numbers such as 1E−13

The TI-84 calculates with decimals, so a value that should be exactly 0 can occasionally come out as a tiny number written in E notation. Treat a result such as 1E−13 as 0. ▸Frac often cleans it up, and the online calculator avoids the problem by using exact fractions throughout.

The original TI-83

The original TI-83 (not the Plus) has its own MATRX key, so press MATRX instead of 2nd x⁻¹ to open the matrix menu. The rest of the steps are the same.

Check the matrix if the result looks wrong.

A wrong sign, a value typed in the wrong cell or an extra row of zeros changes the whole reduction. Open the editor again with 2nd, x⁻¹, →, →, ENTER, confirm the dimensions shown at the top, and compare every entry with your problem before running the command again. For a system of equations, the constants belong in the last column.

See the row operations behind the answer.

The rref( command returns only the final matrix. To see how the calculator gets there, enter the same values in the online RREF calculator, which lists every row operation with exact fractions, or follow the worked example. For a system of equations, the augmented matrix calculator also names the solution type.

TI-84 RREF questions

Where is rref on a TI-84?

Press 2nd, then x⁻¹ to open the MATRIX menu, then the right arrow once to reach MATH. rref( is item B; ALPHA then APPS pastes it directly.

Can the TI-84 show the steps of rref?

No. The rref( command returns only the final matrix. To see every row operation with exact fractions, enter the same matrix in the online RREF calculator.

Why do I get ERR:INVALID DIM?

The rref( and ref( commands need at least as many columns as rows. Add columns of zeros on the right, or use the online calculator, which accepts tall matrices.

How do I get fractions instead of decimals?

Run rref([A])▸Frac: after the command, press MATH, choose ▸Frac and press ENTER.

Does this work on a TI-83?

Yes. On the TI-83 Plus the keys are the same. On the original TI-83, open the matrix menu with the MATRX key.

References: Texas Instruments, support solution 34713 and TI-Basic Developer, rref( command reference. Examples independently calculated with exact arithmetic. Sources checked September 25, 2026.
